Yellow Zinc Plated Carbon Steel Cross Drilled Stepped Bolts Heavy Duty Cable Lock Screws with Transverse Side Hole
PRODUCT PARAMETERS
Description
Product Specifications
| Parameter | Specification / Option |
| Product Name | Yellow Zinc Plated Cross Drilled Stepped Bolt / Cable Lock Screw / Transverse Hole Stud |
| Standard | Non-Standard Custom OEM / Manufactured per Sample or Technical Drawing |
| Thread Size (d) | M4, M5, M6, M8, M10 |
| Step/Head Diameter (D) | 8mm, 10mm, 12mm, 14mm, 16mm (Customizable) |
| Cross Hole Diameter (d2) | 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm (Engineered to wire gauge) |
| Thread Length (L) | 6mm – 30mm |
| Material Grade | Carbon Steel (45# Medium Carbon / Q235 Low Carbon), Alloy Steel, Brass |
| Surface Treatment | Yellow Zinc Electro-Plated, Blue-White Zinc, Black Zinc, Nickel Plated |
| Primary Function | Steel Wire Rope Retaining, Control Cable Stop & Clamping, Tensioning Stud |
| Package | Polybags + Master Export Cartons + Fumigated Wooden Pallet |
| MOQ | 3,000 Pcs (In-stock baseline items accept lower trial quantities) |
Detailed Description
Overview
Our Yellow Zinc Plated Cross-Drilled Stepped Bolts are heavy-duty threaded fasteners designed specifically for mechanical control cable locking and wire rope tensioning. Featuring an enlarged solid cylindrical body with a precision transverse cross-drilled hole, these bolts allow steel cables or control wires to pass through seamlessly before being clamped tight against an opposing bracket or nut.
Cold-headed or CNC machined from high-tensile carbon steel, each bolt undergoes a yellow-zinc passivation treatment for enhanced corrosion resistance and long-term durability in harsh outdoor, agricultural, and automotive environments.
Key Features & Advantages
- Solid Stepped Body Design: The enlarged cylindrical shoulder provides maximum shear strength and a stable clamping surface, resisting deformation under high tension.
- Deburred Transverse Cross Hole: Chamfered entry and exit hole edges prevent sharp burrs from cutting, fraying, or weakening the inner steel control cable.
- Yellow Zinc Corrosion Resistance: Electro-plated yellow zinc coating provides excellent protection against humidity, salt spray, oil, and mud.
- High-Precision Metric Threading: Clean, uniform threads ensure effortless installation with standard hex nuts, lock nuts, or threaded receiving blocks.
5. Main Applications
High-converting category keywords for mechanical, automotive, and hardware buyers:
- 🏍️ Automotive & Motorcycles: Throttle cable stops, clutch wire linkages, choke controls, and parking brake cables.
- 🚜 Agricultural & Garden Machinery: Tiller control cables, lawnmower throttle linkages, and tractor mechanical linkages.
- 🏗️ Industrial Wire Rope Systems: Steel cable tensioners, hanging wire clamps, and safety lanyard retainers.
- ⚙️ Fitness & Light Machinery: Pulley cable stops, equipment selector pin linkages, and mechanical control levers.
6. Packaging & Customization Services
[ Packaging Options ]
- Option A: Standard industrial bulk packaging (500–2,000 pcs per polybag in master carton)
- Option B: Pre-sorted assembly kits (Stepped Bolt + Matched Hex Nut + Flat Washer per bag)
- Option C: Customized retail polybags with barcoded header cards for aftermarket distributors
[ OEM & ODM Customization ]
- Custom Step Diameters (D) and Overall Lengths (L)
- Custom Cross-Hole Diameters (d2) tailored to specific wire rope gauges
- Material upgrades: Stainless Steel 304/316 or High-Strength Alloy Steel
